About Yorkshire Net UK
Official Club Call Sign: Yorkshire Net UK · The Yorkshire Linking Project by Lee M0YDG
This project is fully funded and maintained by myself to keep Yorkshire connected to the world via ham radio.
All systems run on my own hardware, including custom-built repeaters and gateways.
I look forward to chatting on the air! — M0YDG
Systems Overview
- Yorkshire Net UK: Two independent networks running on my own servers.
- D-Star REF011 Reflector: Hosted in the UK.
- All servers run from my personal home data centre with backup power and dual 1Gbps internet lines.
- All Yorkshire Net repeaters are linked via 5.8GHz point-to-point connections, with private IPs—no internet required.
- Repeaters have solar and wind power backups, keeping them operational during outages.
News & Updates
- Portable Repeater (M0XYN): 5W ERP for events around Yorkshire. Frequency and CTCSS will be posted when active.
- KrakenSDR System: Deployed at locations with excellent take-off and low RF noise. Login access for Yorkshire hams will be available soon. Configuration still in progress. Google “KrakenRF” for more details.
Access Requirements
To pass audio between modes, you must have a valid DMR ID and D-Star registration.
Key Systems & TGs
- DV Scotland Phoenix: TG 23450
- FreeDMR: TG 23450
- YorkshireDMR: TG 23450
- YSF Reflectors: GB YorkshireNet 71050, GB YorkshireUK 00026
- D-Star Reflectors: DCS354B (PI-Star), REF011C (G3 DPlus)
- Peanut System: GB DMR23450
- Requests for new TGs accepted via email
- Time Slot 1: Reserved for YorkshireNet 23450 only
DMR YSF & DSTAR Systems
Linked Repeaters in West and South Yorkshire
- GB7BW 439.7250 -9.0MHz YSF GB-YorkshireNet
- GB3YN 430.9875 +7.6MHz CC4 TS1 TG 23450
- GB7YN 430.2875 +9MHz CC3 TS1 TG 23450
- MB5BW 145.5875 -0.6MHz CC5 TS1 TG 23450
- MB5WB-B 439.5375 -9.0MHz D-Star REF011C
- MB5WB-A 1297.125 -6.0MHz D-Star REF011C
- MB6YN 431.0750 Simplex CC4 TS2 TG 23450
DV Repeaters and Gateways Run By Friends
- MB5KT 430.3000 +9MHz CC5 TS1 TG 23450
- MB5SX 430.9500 +7.6MHz CC7 TS1 TG 23450 (Run by Rob M1LOU)
- GB3DV 439.7000 -9MHz CC2 TS1 TG 23450 (Run by Simeon M0VOB)
- MB5DV 432.8000 TX 144.9750 RX CC2 TS1 TG 23450 (Crossband, built by M0YDG, run by Simeon M0VOB)
- MB6JT 144.9125 D-Star DCS354B (Run by Josh M0DIT)
- GB7NA 145.6750 -0.6MHz D-Star REF011C (Run by Ernie G4LUE)
Hotspot Configuration for Yorkshire DMR
Add this to the bottom of your DMR GW in Expert mode with your ID:
[DMR Network 5]
Enabled=1
Address=dmr.m0xyn.radio
Port=62031
TGRewrite2=2,23450,2,23450,2
Password="passw0rd"
Debug=0
Id=YourID
Location=0
Options="TS2_1=23450;TS2_2=23451;"
Name=YorkshireDMR
AV Systems
- Echolink: M0XYN-L
- AllStarLink: Hub1 59862
- Yorkshire SVX Reflector: TG 23450
- SVX Reflector by G4NAB: TG 23450
- VOIP Phone Access available by email registration (Tel: 23450)
SVX Link Repeaters Bridged by Yorkshire SVX Reflector
- GB3BW 430.8125 +7.6MHz
- MB5YN 433.1250 +5MHz
- GB3WP 29.6600 -0.1MHz (auto-connect on RF/audio, key-up alone will not work)
- MB5WP 50.7600 +0.5MHz
- MB7IHG 145.2250 Simplex (battery/solar; enable via DTMF)
- MB7IWP 1297.950 Simplex
AV Repeaters and Gateways Run By Friends
- GB3KT 430.5000 +7.6MHz (Run by Josh M0DIT)
- GB3NA 145.6125 -0.6MHz (Run by Ernie G4LUE)
- MB7IBY 145.3125 Simplex (Run by Rob M1LOU)
- MB7IAV 145.3375 Simplex (Run by Simeon M0VOB)
- More info on repeater settings: ukrepeater.net
DMR TG Access (Time Slot 2)
- UK Chat 1–5: 80–84, UK Calling 235
- Regional TGs: SE 801, SW 810, NW 820, Midlands 830, East 840, NE 860, Wales & Marches 870, N. Ireland 880
- UK Wide Multimode: 23556
- Brandmeister TGs: BM UK Calling 2350, BM UK Chat 1–3
- YorkshireDMR TGs: Ears Radio 23451, Extended Freedom Network 23525, CQ North 2345
